Problem Statement:

Data Mart is Danny’s latest venture and after running international operations for his online supermarket that specialises in fresh produce - Danny is asking for your support to analyse his sales performance.

In June 2020 - large scale supply changes were made at Data Mart. All Data Mart products now use sustainable packaging methods in every single step from the farm all the way to the customer.

Danny needs your help to quantify the impact of this change on the sales performance for Data Mart and it’s separate business areas.

Solution:

This is a case study and is part of a 8 part series of 8 different case studies that focus on different aspects of a business.

In this case study we will answer the following:

What was the quantifiable impact of the changes introduced in June 2020?
Which platform, region, segment and customer types were the most impacted by this change?
What can we do about future introduction of similar sustainability updates to the business to minimise impact on sales?

The database schema and information about the data attributes can be found here: https://8weeksqlchallenge.com/case-study-5/

Data Cleaning:

We will need to clean up the data a bit before we can proceed with solving it.

SET
  search_path = data_mart;
SELECT
  date AS week_date,
  EXTRACT(
    WEEK
    FROM
      date
  ) :: int AS week_number,
  EXTRACT(
    MONTH
    FROM
      date
  ) :: int AS month_number,
  EXTRACT(
    YEAR
    FROM
      date
  ) :: int AS calendar_year,
  region,
  platform,
  CASE
    WHEN segment = 'null' then 'unknown'
    ELSE segment
  END AS segment,
  CASE
    WHEN substr(segment, 2, 1) = '1' then 'Young Adults'
    WHEN substr(segment, 2, 1) = '2' then 'Middle Aged'
    WHEN substr(segment, 2, 1) in ('3', '4') then 'Retirees'
    ELSE 'unknown'
  END AS age_band,
  CASE
    WHEN substr(segment, 1, 1) = 'C' then 'Couples'
    WHEN substr(segment, 1, 1) = 'F' then 'Families'
    ELSE 'unknown'
  END AS demographic,
  customer_type,
  transactions,
  sales,
  avg_transaction INTO clean_weekly_sales
FROM
  weekly_sales,
  LATERAL (
    SELECT
      TO_DATE(week_date, 'DD/MM/YY') AS date
  ) date,
  LATERAL (
    SELECT
      ROUND((sales :: numeric / transactions), 2) AS avg_transaction
  ) avt
ORDER BY
  calendar_year

2. Data Exploration

1. What day of the week is used for each week_date value?

SET
  search_path = data_mart;
SELECT
  EXTRACT(
    ISODOW
    FROM
      week_date
  ) AS day_of_week
FROM
  clean_weekly_sales
GROUP BY
  1

day_of_week
1

Each week starts from Monday in the week_date table

2. What range of week numbers are missing from the dataset?

We can get a range of the weeks that are in our table:

SET search_path = data_mart;
SELECT
  week_number
FROM
  clean_weekly_sales
GROUP BY
  1
ORDER BY
  1

week_number
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36

SET
  search_path = data_mart;
WITH series as (
    SELECT
      GENERATE_SERIES(1, 52) as missing_weeks
    FROM
      clean_weekly_sales
  )
SELECT
  missing_weeks
FROM
  series
WHERE
  missing_weeks NOT IN(
    SELECT
      week_number
    FROM
      clean_weekly_sales
  )
GROUP BY
  1
ORDER BY
  1

missing_weeks
1
2
3
4
5
6
7
8
9
10
11
12
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52

Weeks 1 - 12 and 37 - 52 are missing from the dataset.

3. How many total transactions were there for each year in the dataset?

We need to group all the transactions by years and count the total number of transaction using SUM function.

SELECT
  calendar_year,
  SUM(transactions) AS total_transactions
FROM
  clean_weekly_sales
GROUP BY
  1
ORDER BY
  1

calendar_year	total_transactions
2018	346406460
2019	365639285
2020	375813651

The number of transactions are increasing year by year.

4. What is the total sales for each region for each month?

SELECT
  region,
  month_number,
  SUM(sales) AS total_sales
FROM
  clean_weekly_sales
GROUP BY
  1, 2
ORDER BY
  1,2

region	month_number	total_sales
AFRICA	3	567767480
AFRICA	4	1911783504
AFRICA	5	1647244738
AFRICA	6	1767559760
AFRICA	7	1960219710
AFRICA	8	1809596890
AFRICA	9	276320987
ASIA	3	529770793
ASIA	4	1804628707
ASIA	5	1526285399
ASIA	6	1619482889
ASIA	7	1768844756
ASIA	8	1663320609
ASIA	9	252836807
CANADA	3	144634329
CANADA	4	484552594
CANADA	5	412378365
CANADA	6	443846698
CANADA	7	477134947
CANADA	8	447073019
CANADA	9	69067959
EUROPE	3	35337093
EUROPE	4	127334255
EUROPE	5	109338389
EUROPE	6	122813826
EUROPE	7	136757466
EUROPE	8	122102995
EUROPE	9	18877433
OCEANIA	3	783282888
OCEANIA	4	2599767620
OCEANIA	5	2215657304
OCEANIA	6	2371884744
OCEANIA	7	2563459400
OCEANIA	8	2432313652
OCEANIA	9	372465518
SOUTH AMERICA	3	71023109
SOUTH AMERICA	4	238451531
SOUTH AMERICA	5	201391809
SOUTH AMERICA	6	218247455
SOUTH AMERICA	7	235582776
SOUTH AMERICA	8	221166052
SOUTH AMERICA	9	34175583
USA	3	225353043
USA	4	759786323
USA	5	655967121
USA	6	703878990
USA	7	760331754
USA	8	712002790
USA	9	110532368

We can see that Oceania generates most of the sales, followed by Africa and Asia.

5. What is the total count of transactions for each platform?

SELECT
  platform,
  SUM(transactions) as total_transactions
FROM
  clean_weekly_sales
GROUP BY
  1
ORDER BY
  1

platform	total_transactions
Retail	1081934227
Shopify	5925169

Retail has more transactions than Shopify.

6. What is the percentage of sales for Retail vs Shopify for each month?

SELECT
  sr.month_number,  sr.calendar_year,  ROUND(100 *(SUM(sales) :: numeric / total_sales_s), 1) AS percentage_of_sales_retail,
  100 - ROUND(100 *(SUM(sales) :: numeric / total_sales_s), 1) AS percentage_of_sales_shopify
FROM
  clean_weekly_sales AS R
  JOIN (
    SELECT
      S.month_number, S.calendar_year, SUM(sales) AS total_sales_s
    FROM
      clean_weekly_sales AS S
    GROUP BY
      S.month_number,
      S.calendar_year
  ) S ON sr.month_number = S.month_number
  and S.calendar_year = R.calendar_year
WHERE
  R.platform = 'Retail'
GROUP BY
  R.month_number, R.calendar_year, total_sales_s
ORDER BY
  2,  1

month_number	calendar_year	percentage_of_sales_retail	percentage_of_sales_shopify
3	2018	97.9	2.1
4	2018	97.9	2.1
5	2018	97.7	2.3
6	2018	97.8	2.2
7	2018	97.8	2.2
8	2018	97.7	2.3
9	2018	97.7	2.3
3	2019	97.7	2.3
4	2019	97.8	2.2
5	2019	97.5	2.5
6	2019	97.4	2.6
7	2019	97.4	2.6
8	2019	97.2	2.8
9	2019	97.1	2.9
3	2020	97.3	2.7
4	2020	97.0	3.0
5	2020	96.7	3.3
6	2020	96.8	3.2
7	2020	96.7	3.3
8	2020	96.5	3.5

Retail takes a significant share in the total sales but share is gradually decreasing.

7. What is the percentage of sales by demographic for each year in the dataset?

SELECT
  s.calendar_year,  demographic,  ROUND(100 *(SUM(sales) :: numeric / total_sales), 1) AS percentage
FROM
  clean_weekly_sales AS S
  JOIN (
    SELECT
      cSUMalendar_year,
      SUM(sales) AS total_sales
    FROM
      clean_weekly_sales AS T
    GROUP BY
      calendar_year
  ) T ON S.calendar_year = T.calendar_year
GROUP BY
  1, 2, total_sales
ORDER BY
  1, 2

calendar_year	demographic	percentage
2018	Couples	26.4
2018	Families	32.0
2018	unknown	41.6
2019	Couples	27.3
2019	Families	32.5
2019	unknown	40.3
2020	Couples	28.7
2020	Families	32.7
2020	unknown	38.6

8. Which age_band and demographic values contribute the most to Retail sales?

SELECT
  age_band, demographic,  SUM(sales) AS total_sales
FROM
  clean_weekly_sales
WHERE
  platform = 'Retail'
GROUP BY
  1,  2
ORDER BY
  3 DESC, 1, 2

We can see that most of age band and demographic characteristics of our users are unknown. Among the others, Families and Retirees contribute in retail sales the most.Now getting the maximum sales for age band and for demographic, excluding unknown values.

SELECT
  age_band, total_sales, percentage_of_sales
FROM
  (
    SELECT
      age_band,
      SUM(sales) AS total_sales,  round(100 * (SUM(sales) :: numeric / all_sales), 1) AS percentage_of_sales,
      row_number() over (
        ORDER BY
          SUM(sales) DESC
      )
    FROM
      clean_weekly_sales,
      LATERAL (
        SELECT
          SUM(sales) AS all_sales
        FROM
          clean_weekly_sales
      ) S
    WHERE
      platform = 'Retail'
      AND demographic != 'unknown'
    GROUP BY
      1, all_sales
  ) T
WHERE
  row_number = 1

age_band	total_sales	percentage_of_sales
Retirees	13005266930	31.9

SELECT
  demographic,  total_sales,  percentage_of_sales
FROM
  (
    SELECT
      demographic,  SUM(sales) AS total_sales,
      round(100 * (SUM(sales) :: numeric / all_sales), 1) AS percentage_of_sales,
      row_number() over (
        ORDER BY
          SUM(sales) DESC
      )
    FROM
      clean_weekly_sales,
      LATERAL (
        SELECT
          SUM(sales) AS all_sales
        FROM
          clean_weekly_sales
      ) S
    WHERE
      platform = 'Retail'
      AND demographic != 'unknown'
    GROUP BY
      1, all_sales
  ) T
WHERE
  row_number = 1

demographic	total_sales	percentage_of_sales
Families	12759667763	31.3

SELECT
  demographic,
  age_band,
  total_sales,
  percentage_of_sales
FROM
  (
    SELECT
      demographic, age_band,  SUM(sales) AS total_sales,
      round(100 * (SUM(sales) :: numeric / all_sales), 1) AS percentage_of_sales,
      row_number() over (
        ORDER BY
          SUM(sales) DESC
      )
    FROM
      clean_weekly_sales,
      LATERAL (
        SELECT
          SUM(sales) AS all_sales
        FROM
          clean_weekly_sales
      ) S
    WHERE
      platform = 'Retail'
      AND demographic != 'unknown'
    GROUP BY
      1, 2, all_sales
  ) T
WHERE
  row_number = 1

demographic	age_band	total_sales	percentage_of_sales
Families	Retirees	6634686916	16.3

The age group of retirees and the demographic group of families and the combined group of retired families contribute the most to retail sales.

9. Can we use the avg_transaction column to find the average transaction size for each year for Retail vs Shopify? If not - how would you calculate it instead?

We can not use avg_transaction column to find the average transaction size per year and sales platform, because we need to aggregate it first. since we can not use the average of average to calculate the average.

SELECT
  calendar_year, platform, ROUND(SUM(sales) :: numeric / SUM(transactions), 1) AS correct_avg,
  ROUND(AVG(avg_transaction), 1) AS incorrect_avg
FROM
  clean_weekly_sales
GROUP BY
  1, 2
ORDER BY
  1, 2

calendar_year	platform	correct_avg	incorrect_avg
2018	Retail	36.6	42.9
2018	Shopify	192.5	188.3
2019	Retail	36.8	42.0
2019	Shopify	183.4	177.6
2020	Retail	36.6	40.6
2020	Shopify	179.0	174.9

3. Before & After Analysis

This technique is usually used when we inspect an important event and want to inspect the impact before and after a certain point in time.

Taking the week_date value of 2020-06-15 as the baseline week where the Data Mart sustainable packaging changes came into effect.

We would include all week_date values for 2020-06-15 as the start of the period after the change and the previous week_date values would be before

1. What is the total sales for the 4 weeks before and after 2020-06-15? What is the growth or reduction rate in actual values and percentage of sales?

WITH sales_before AS (
    SELECT
      SUM(sales) AS total_sales_before
    FROM
      clean_weekly_sales,
      LATERAL(
        SELECT
          EXTRACT(
            WEEK
            FROM
              '2020-06-15' :: date
          ) AS base_week
      ) B
    WHERE
      calendar_year = 2020
      AND week_number between (base_week - 4)
      AND (base_week - 1)
  ),
  sales_after AS (
    SELECT
      SUM(sales) AS total_sales_after
    FROM
      clean_weekly_sales,
      LATERAL(
        SELECT
          EXTRACT(
            WEEK
            FROM
              '2020-06-15' :: date
          ) AS base_week
      ) B
    WHERE
      calendar_year = 2020
      AND week_number between (base_week)
      AND (base_week + 3)
  )
SELECT
  total_sales_before, total_sales_after, total_sales_after - total_sales_before AS change_in_sales,
  ROUND(
    100 * (total_sales_after - total_sales_before) :: numeric / total_sales_before,
    2
  ) AS percentage_of_change
FROM
  sales_before,
  sales_after

total_sales_before	total_sales_after	change_in_sales	percentage_of_change
2345878357	2318994169	-26884188	-1.15

The total sales for 4 weeks after week 25 decreased to 1.15% compared to 4 week sales before week 25

2. What about the entire 12 weeks before and after?

WITH sales_before AS (
    SELECT
      SUM(sales) AS total_sales_before
    FROM
      clean_weekly_sales,
      LATERAL(
        SELECT
          EXTRACT(
            WEEK
            FROM
              '2020-06-15' :: date
          ) AS base_week
      ) B
    WHERE
      calendar_year = 2020
      AND week_number between (base_week - 12)
      AND (base_week - 1)
  ),
  sales_after AS (
    SELECT
      SUM(sales) AS total_sales_after
    FROM
      clean_weekly_sales,
      LATERAL(
        SELECT
          EXTRACT(
            WEEK
            FROM
              '2020-06-15' :: date
          ) AS base_week
      ) B
    WHERE
      calendar_year = 2020
      AND week_number between (base_week)
      AND (base_week + 11)
  )
SELECT
  total_sales_before,  total_sales_after,
  total_sales_after - total_sales_before AS change_in_sales,
  ROUND(
    100 * (total_sales_after - total_sales_before) :: numeric / total_sales_before,
    2
  ) AS percentage_of_change
FROM
  sales_before,  sales_after

total_sales_before	total_sales_after	change_in_sales	percentage_of_change
7126273147	6973947753	-152325394	-2.14

The total sales for 12 weeks after week 25 decreased to 2.14% compared to 12 week sales before week 25

3. How do the sale metrics for these 2 periods before and after compare with the previous years in 2018 and 2019?

WITH sales_before AS (
    SELECT
      calendar_year,
      SUM(sales) AS total_sales_before
    FROM
      clean_weekly_sales,
      LATERAL(
        SELECT
          EXTRACT(
            WEEK
            FROM
              '2020-06-15' :: date
          ) AS base_week
      ) bw
    WHERE
      week_number between (base_week - 12)
      AND (base_week - 1)
    group by
      1
  ),
  sales_after AS (
    SELECT
      calendar_year,  SUM(sales) AS total_sales_after
    FROM
      clean_weekly_sales,
      LATERAL(
        SELECT
          EXTRACT(
            WEEK
            FROM
              '2020-06-15' :: date
          ) AS base_week
      ) B
    WHERE
      week_number between (base_week)
      AND (base_week + 11)
    group by
      1
  )
SELECT
  sb.calendar_year, total_sales_before,  total_sales_after,
  total_sales_after - total_sales_before AS change_in_sales,
  ROUND(
    100 * (total_sales_after - total_sales_before) :: numeric / total_sales_before,
    2
  ) AS percentage_of_change
FROM
  sales_before AS S
  JOIN sales_after AS B ON S.calendar_year = B.calendar_year
group by
  1, 2, 3

calendar_year	total_sales_before	total_sales_after	change_in_sales	percentage_of_change
2018	6396562317	6500818510	104256193	1.63
2019	6883386397	6862646103	-20740294	-0.30
2020	7126273147	6973947753	-152325394	-2.14

We can see sales increased in 2018, and sales fell in 2019 and 2020 with 2020 having the worst performance.

Alvee Chowdhury
